• Active Transit /Cutting speeds 1200/1000 IPM
  • Mechanical home switches
  • R and P on X and Y Drives, Ball Screw on z axis
  • Power 220
  • Easy to use G-code controller
  • Anti Backlash
Router FeaturesSpecifications
Table Size72" x 144"
X,Y,Z Working Area61" x 121" x 12"
X,Y,Z, Traveling Position Accuracy+/-.002"
Frame StructureSteel
X.Y StructureAnti backlash Rack and Pinion
Z StructureOrbital Ball Screw
Max Speed0-1200 IPM
Max Working Speed0-1000 IPM
Spindle Power MotorHigh Frequency Conversion Water Cooled Motor
Working Mode24000r/min
Tool Changer8 Bit - BT30
Working VoltageAC220V
CommandIncludes MACH controller, G Code, dxf
InterfacePC
XY Working Tolerance< 0.02mm
SoftwareMach3, Type3 full function 3d
Packing Size91" x 156" x 44"
Net Weight2,100 lbs
